Inpro/Seal VB45-S Bearing Isolator Provides Permanent Bearing Protection

Print Print this Article | Send to Colleague


The Inpro/Seal® VB45-S™ Bearing Isolator continues the Inpro/Seal (Rock Island, Ill., USA) line of Bearing Isolator designs that increase equipment reliability through permanent bearing protection.

Like all Inpro/Seal Bearing Isolators, the VB45-S design protects against contamination ingress and lubrication loss. The VB45-S Bearing Isolator utilizes Inpro/Seal’s patented XX Interface coupled with an enlarged contamination chamber to achieve an IP66 rating, the standard for premium ingress protection against both harmful particulates and liquids, making it one of the best performing Bearing Isolators available

For superior protection against lubrication loss, the VB45-S utilizes either an enlarged D-Groove to capture oil and return it to the bearing housing or a grease band to block grease from traveling down the shaft and escaping from the bearing housing.

With an overall (axial) length of only 0.625 in. (15.88 mm), the VB45-S Bearing Isolator is the most compact IP66 rated Bearing Isolator available. A short overall length allows for easy installation, often without the need for equipment modifications. The VB45-S Bearing Isolator, as with all Inpro/Seal Bearing Isolators, can be shipped the same day orders are placed, ensuring customers get their equipment operating as quickly as possible

Inpro/Seal has been delivering innovative sealing solutions and outstanding customer service for more than 40 years. The company’s unique technologies increase the reliability of rotating equipment and provide real cost savings by improving the mean time between repair (MTBR). Additional information is available online. Click here to locate a representative.

Inpro/Seal is an operating company of Dover, Downers Grove, Ill. Additional information about Dover also is available online.
